Overband Magnetic Separator


Overband Magnetic Separator (OBMS)

Shree Vishwakarma Magnets manufactures Over Band Magnetic Separators that are designed to eliminate tramp metal from the product carried by a belt, vibratory feeders or by inclined planes. Overbands are mainly used to protect machines such as crushers, shredders, and others, to remove ferrous particles and purify products (Industries like Foundries, Coal Mines,Stone, Cement Works, Food, Sponge Iron, Charcoal, Glass, Domestic waste recycling Plants). Permanent Magnetic over Band Separators are used when an automatic removal of ferrous contamination is necessary. If not then fixed permanent suspension magnets are more preferable

Shree Vishwakarma Magnets is a leading manufacturer of Overband Magnetic Separators in India. The Overband Magnetic Separator is designed to remove ferrous and non-ferrous contaminants from conveyed materials. The device consists of a belt and two pulleys - a magnet pulley and a drive pulley. The magnet pulley is positioned over the conveyor belt and generates a strong magnetic field, attracting and holding onto the magnetic particles.

Overband Magnetic Separator is made with high-quality materials and advanced technology, ensuring reliable performance and long service life. The device is easy to install and maintain, making it a popular choice among various industries. The Overband Magnetic Separator is widely used in mining, cement, recycling, and other industries for the efficient separation of magnetic particles.

Overband Magnetic Separators are customizable to meet the specific needs of their customers. They are committed to providing the best quality products and exceptional customer service. As a leading supplier, and exporter of Overband Magnetic Separators in India, Vishwakarma Magnets has built a strong reputation for delivering innovative and cost-effective solutions to their clients.

Salient Features

Used in either ceramic or powerful rare earth magnet.

Separator body covering.

Low maintenance

Roughest construction

High efficiency of separation

Long belt life

Specification

Used in either ceramic or powerful rare earth magnet.

Separator body covering.

Low maintenance

Roughest construction

High efficiency of separation

Long belt life

The attraction distance trial is taken at a point below the geometrical center point of the suspended magnet assembly.

The above results are obtained when free path is available for tramp iron particle.

The above chart is given for the reference. One may get a deviation of 1 to 2 inches in attraction distance depending on actual conditions.

Two U-section pieces are fixed on the Magnet by fastening ears and are supporting bearings of Drums. Drums are equipped with shafts mounted on removable hubs. All bearings equipped with stakes for tightening the belt.

The belt is driven by a Reduction Gear Coupled to Electric Motor / Geared Motor by V-belts.

The Magnet is made of High-Intensity Strontium Ferrite / Rare Earth Magnets and is guaranteed for the Magnetic Power throughout the life of the installation. A Non – Magnetic Stainless steel Plate is provided to cover the poles of Magnet. There is no need for any electrical supply or maintenance.
